HYT-350B automatic hydraulic hose cutting machine

HYT-350B automatic hydraulic hose cutting machine

HYT-350B Automatic Hose Cutting Machine is used to cut large hydraulic hoses. The wire cutting blade is made of a powerful cylinder which uses a pneumatic pedal type to control the cutting action.The cutting blade is hard, strong and long-lasting to cut large lengthsof hydraulic hoses.

The Technical Parameter of HYT-350B automatic hydraulic hose cutting machine

1. Working Range (Inner Diameter): 1/8~2"（ 6~51mm ）

2. Max φ 80mm

6.Working cycle: penumatic

3.Blade:φ 350mm

4.Voltage : 380V/5.5Kw

5.Speed: 2900r/min

6.Range: 125mm

Noise Level: ≦75dB

7. Machine dimension:810*635*1300mm

8. Package Dimension:1030*730*1520mm

9.Weight(N./W./G.W.): 163kg/190kg

Recessed blade for the operator's safety

The foot switch Mechanical &pedal control

Its motor for driving the knife is easily controlled using a foot pedal which allows the operator to use both hands for guiding the hose through the process.

Suction connection.Cooling atomized smoking dust collector Energy saving and environmental protection high degree of automation

Application Industries

Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Farms, Retail, Construction works , Energy & Mining, Advertising Company

Operation instruction of hose cutting machine :

(1) Plug in. Check whether the direction of rotation of the cutting blades is consistent with the direction of arrow. (Reversing prohibited)

 (2) Adjust the positioning cock according to the diameter of the cut pipe in case there would be slant and slice problems.

 (3) Put the cut pipe in place. Push the feed lever. Fulfill the cutting process.

Addition information

Paymets Terms: T/T ( Bank transfer ), Western Union, Paypal , Credit Card, Online pay etc.

Delivery method:  wooden case package ; By sea to any port .

Production Capacity: 200 sets per month

Delivery Time: 3~7 days
